Recron 3S Fiber

Recron® 3s Fibres are Engineered Micro Fibres with a unique “Triangular” Cross-section, used in Secondary Reinforcement of Concrete. It complements Structural Steel in enhancing Concrete’s resistance to Shrinkage Cracking and improves mechanical properties such as Flexural / Split Tensile and Transverse Strengths of Concrete along with the desired improvement in Abrasion and Impact Strengths.

PRIMARY APPLICATIONS

  • Pavement quality Concrete
  • Foundations / Retaining
  • Floorings / Grade Slabs
  • Walls Shotcrete
  • Decks/Overlays
  • Roof Slabs
  • Bridge
Products Catalogue

FEATURES AND BENEFITS

  • Improves Resistance to Plastic & Drying Shrinkage Cracking
  • Improves Flexural Toughness / increases Split Tensile Strength
  • Inhibits growth of Cracks-bridges Micro-Cracks and provides stability to Concrete
  • Enhances Abrasion Resistance & increases Energy Absorption of Concrete thereby improving Impact Resistance
  • Acts as a Pumping aid in making Concrete more homogenous
  • Reduces Surface Water Absorption / Permeability in Concrete
  • Improves Durability and enhances Longevity of Concrete/Structure

PERFORMANCE DATA

Properties Units Polyester polypropylene Remarks

Shape

-

Triangular

Triangular

-

Cut Length

mm

3 / 4.8 / 6 / 12 / 18 /24

3 / 4.8 / 6 / 12 / 18 /24

+/- 1 mm Project Specific
Customized lengths can be
produced on request

Effective Diameter

microns

20 - 40

25 - 40

-

Specific Gravity

-

1.34 - 1.39

0.90 - 0.91

-

Melting Point

Deg.C

250 - 265

160 - 165

-

Tensile strength

GPD

4 - 6*

4 - 6*
*Estimated Tensile Strength in Mpa 4 - 6
*polyester 480 - 730
polypropylene 320 - 490

Elongation

%

20 - 60

60 - 90

Initial Modulus

Young's Modulus

Mpa

>5000

>4000

Test done as Per AC

Alkaline Stability

-

Very Good

Very Good

32 Standards
